Suzhou Renowell Hydraulic Pump Co., Ltd.
7 Years
| Ask Lasest Price | |
| Brand Name : | Renowell |
| Model Number : | Vickers V/ VQ |
| Supply Ability : | 2000 Piece/Pieces per Month |
| Price : | Negotiable |
| Certification : | ISO9001 |
Characteritics
High Performance Intravane Pumps for plastic injection machinery,
Shoe machinery, Tool machinery, Die casting machinery and
Metallurge equipment.
1.Intravane pumps with hydraulic balancing structure provide more
stable performance and longer life since less pressure from vane on
stator.
2.Twelve vane system provide low amplitude flow pulsation resulting
in low system noise characteristics.
3.Verious displacement and shafts with 4 different outlet opposite
position make operation more flexible.
4.The cartridge is independent of the drive shaft, allowing for
easy servicing without remore the pump from its mounting.
V series Pump:
20V, 25V, 35V, 45V, 2520V, 3520V, 3525V, 4520V, 4525V, 4535V
VQ Series pump:
20VQ, 25VQ, 35VQ, 45VQ, 2520VQ, 3520VQ, 3525VQ, 4520VQ, 4525VQ,
4535VQ
Usage :
Hydraulic vane pump are widely used in Heavy equipments, Mining
machinery,Rubber & Plastic machinery, Shoes machinery, Die Casting
Machinery, Metallurgical machinery, Metal Cutting Machinery and
other types of hydraulic syste
| Series | Flow code (USgpm) | Geometric displacement ml/r | Max.operating pressure Mpa | Max.speed r/min | Min. Speed r/min |
| 20VQ | 2 | 7(0.43) | 21 | 2700 | 600 |
| 3 | 10(0.61) | ||||
| 4 | 13(0.79) | ||||
| 5 | 16.5(1.01) | ||||
| 6 | 19(1.16) | ||||
| 7 | 22(1.40) | ||||
| 8 | 27(1.67) | ||||
| 9 | 30(1.85) | ||||
| 10 | 31.5(1.92) | ||||
| 11 | 35(2.14) | ||||
| 12 | 40(2.44) | 16 | |||
| 14 | 45(2.78) | 14 | |||
| 25VQ | 10 | 32(1.95) | 21 | 2700 | 600 |
| 12 | 38(2.32) | ||||
| 14 | 43.5(2.65) | ||||
| 15 | 47(2.89) | 2500 | |||
| 17 | 54(3.30) | ||||
| 19 | 60(3.66) | ||||
| 21 | 67(4.13) | ||||
| 25 | 79.2(4.83) | ||||
| 35VQ | 21 | 67(4.13) | 21 | 2500 | 600 |
| 25 | 81(4.94) | ||||
| 30 | 95(5.80) | ||||
| 32 | 101(6.16) | ||||
| 35 | 109(6.65) | 2400 | |||
| 38 | 119(7.26) | ||||
| 45 | 143(8.72) | 14 | |||
| 45VQ | 42 | 134(8.17) | 17.5 | 2400 | 600 |
| 45 | 143(8.72) | 2200 | |||
| 50 | 159(9.70) | ||||
| 57 | 181(11.05) | ||||
| 60 | 189(11.53) | ||||
| 66 | 210(12.81) | ||||
| 75 | 237(14.46) | 14 |
|
